Multichannel Optical Power Meter 1510~1625 Nm Continuous Calibration

Name: Multichannel Optical Power Meter 15101625 Nm Continuous Calibration
Brand: YOUCii
Price: 1 USD

Brand Name : YOUCii

Model Number : U8724C/U8728C

Place of Origin : CHINA

MOQ : 1pcs

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram, T/T

Certification : CU,IOS

Price : negotiate a price

Supply Ability : 20 pcs+per month

Delivery Time : 20 work days

Packaging Details : Carton

Sensor Element : InGaAs

Calibration Wavelength : 850/980/1310/1490/1550/1610 nm/1510~1625 nm Continuous calibration

Application Fiber Type : Standard SM and MM up to 62.5 um core size

Uncertainty (accuracy) : ± 4% (1200 nm ~ 1610 nm)

Linearity (power) : ≤ ± 0.06 dB (1200 nm ~ 1610 nm, 0~ -60dBm)

Operation Temperature : 0～ +40 ℃

Contact Now

Multichannel Optical Power Meter 1510~1625 Nm Continuous Calibration

Product introduction:

U8724/8 4/8 Channel optical power meters offer superior performance for the testing of DWDM components, AWG &PLC components, optical amplifiers, and other general purpose of fiber optical test and measurement applications. It is specifically designed for use in high volume prodUtion lines.

U8724 optical power meter test systems are efficient, compact sized, fast-starting, and affordable. Guangzhou U can provide low power, high power 4 channel and 8 channel optical power meter for choice, and can also provide up to 64 channel combination test system for customers.

U8724/8 technical specification:

Model #	U8724/8A	U8724/8B	U8724/8C
Sensor Element	InGaAs
Wavelength Range	850 ~ 1700 nm
Calibration Wavelength	850/980/1310/1490/1550/1610 nm		1510~1625 nm Continuous calibration
Power Range	+10 ~ -65dBm	+25~-55dBm	+5~-75dBm
Sampling period	100us (10KHz)		10 us (100KHz)
Application Fiber Type	Standard SM and MM up to 62.5 um core size
Uncertainty (accuracy)	± 4% (1200 nm ~ 1610 nm)
Relative Uncertainty (accuracy)	＜ 0.02 dB Typical
Linearity (power)	≤ ± 0.06 dB (1200 nm ~ 1610 nm, 0~ -60dBm)
Return Loss	＞40 dB
Communication Interface	RS232, USB,Control by PC
Operation Temperature	0 ～ +40℃
Storage Temperature	-30 ～ +80℃
Recalibration Period	2 years
Dimensions	235 mm W, 55mm H, 320 mm D
Weight	3.0 kg

Multichannel Optical Power Meter 1510~1625 Nm Continuous Calibration

Product Tags:

Multichannel Optical Power Meter

1625Nm Optical Power Meter

Multichannel Optical Power Meter 1510~1625 Nm Continuous Calibration Images
